Basic Information
Capacity: 1 tph – 20 tph
Pressure: 0.7 Mpa – 2.0 Mpa
Fuel: Nature gas, coke oven gas, biogas, methanol, liquid propane gas, diesel, heavy oil, light oil, crude oil, etc.
Applicable Industries: Heat supplying, chemical, food, textile, printing and dyeing, cigarettes and tobacco, fodder, pharmacy, building materials, brewery, rubber, hospital etc.
Place of Origin: Jiangsu, China
Dimension(L*W*H): Depends on the boiler capacity
Port: Shanghai/Tianjin/Qingdao
Product Description
WSN series gas / oil fired industrial horizontal steam boiler is a kind of safety and high efficiency heating equipment with fully automatic intelligent control system. It’s a boiler shell type 3 passes wetback oil/gas fired boiler. Usually, the WNS series steam boilers widely used for industry production and processing, such as textile mill, medicine industry, food & beverage industry, chemical industry, garment industry, food processing industry, and wood processing industry, moreover, it could be used for central heating in enterprise, hotel, hospital, civil architecture, etc.
Technical Advantages
High Safety Performance
Fully automatic control system ensures normal running of combustion, water level, temperature and steam pressure.
Pressure controller, pressure transmitter, water level alarm, safety valve and other safety protection devices.
The smoke box door design with open window hinges makes inspection, cleaning and maintenance easier.
Easy Operation and Maintenance
WNS series horizontal steam boiler products in the design of the compact structure, can be opened the smoke box, man-hole, hand-hole, platform ladder and etc design also make it easier for customers to install and maintain.
High Efficiency
WNS series horizontal boiler adopts large diameter full corrugated furnace, which increases combustion space and combustion efficiency.
Through continuous optimization, the heat transfer coefficient of the special threaded smoke tube reaches 1.2 times that of the ordinary smoke tube when the selection of the contract pitch of the thread groove depth meets the minimum flow resistance.
Product Parameters
| Model | Rated steam capacity（t/h） | Rated working pressure（Mpa） | Rated steam temperature（℃） |
| WNS1-0.7-Y(Q) | 1 | 0.7 | 170 |
| WNS1-1.0-Y(Q) | 1 | 1 | 184 |
| WNS1.5-1.0-Y(Q) | 1.5 | 1 | 184 |
| WNS1.5-1.25-Y(Q) | 1.5 | 1.25 | 194 |
| WNS2-1.0-Y(Q) | 2 | 1 | 184 |
| WNS2-1.25-Y(Q) | 2 | 1.25 | 194 |
| WNS3-1.0-Y(Q) | 3 | 1 | 184 |
| WNS3-1.25-Y(Q) | 3 | 1.25 | 194 |
| WNS4-1.25-Y(Q) | 4 | 1.25 | 194 |
| WNS4-1.6-Y(Q) | 4 | 1.6 | 204 |
| WNS5-1.25-Y(Q) | 5 | 1.25 | 194 |
| WNS5-1.6-Y(Q) | 5 | 1.6 | 204 |
| WNS6-1.25-Y(Q) | 6 | 1.25 | 194 |
| WNS6-1.6-Y(Q) | 6 | 1.6 | 204 |
| WNS8-1.25-Y(Q) | 8 | 1.25 | 194 |
| WNS8-1.6-Y(Q) | 8 | 1.6 | 204 |
| WNS10-1.25-Y(Q) | 10 | 1.25 | 194 |
| WNS10-1.6-Y(Q) | 10 | 1.6 | 204 |
| WNS15-1.25-Y(Q) | 15 | 1.25 | 194 |
| WNS15-1.6-Y(Q) | 15 | 1.6 | 204 |
| WNS20-1.25-Y(Q) | 20 | 1.25 | 194 |
| WNS20-1.6-Y(Q) | 20 | 1.6 | 204 |
